Diameter |
M18 |
![]() |
2-15mm |
Housing Material | Nickel plated brass |
![]() ![]() |
![]() |
Max Load Current | 250mA |
Supply Voltage | 10-30 voltDC |
Switching Frequency | 100Hz |
Response Time | 1.5ms/1.5ms |
Protecting category | IP67 |
Operating Temperature | -25ºC- +70ºC |
Short Circuit Protection | Yes |
Connecting Type | M12 connector |
DC 3 wire 10-30V NPN N.O. | CBS-M1808N-A1ES4 |
DC 3 wire 10-30V NPN N.C. | CBS-M1808N-B1ES4 |
DC 3 wire 10-30V PNP N.O. | CBS-M1808P-A1ES4 |
DC 3 wire 10-30V PNP N.C. | CBS-M1808P-B1ES4 |
